Pala gommata nuova Qingdao Promising 2.8T Capacity Compact Wheel Loader with CE ZL28F Gasolio

2.8 ton Capacity automatic transmission wheel loader with enclosed tilt cabin, adjustable suspension seat, digital radio & MP3 player, reversing camera, top beacon; and optional hydraulic joystick control, hydraulic quick attach and air conditioner

Compact Wheel Loader ZL28F
Technical Specifications:
1. Rated Load: 2800kg
2. Operating Weight: 6200kg
3. Rated Bucket Capacity: 1.4CBM
4. Bucket Width: 2150mm
5. Max. Breakout Force: 64KN
6. Max. Tilt Angle of Cabin: 30deg.
7. Max. Dumping Height: 3500mm
8. Max. Dumping Reach: 1300mm
9. Raising Time: less than 6.0s
10. Min. Ground Clearance: 380mm
11. Overall Dimensions (L x W x H): 6570x2200x2850mm
12. Min. Turning Radius: 4800mm
13. Engine Model: DONGFANGHONG YT4B2Z-24 Turbocharged Engine
14. Engine Type: Four-cylinder, Inline, Water-cooled Evaporative, Four-stroke Diesel Engine
15. Rated Engine Power: 74.9kW
16. Rated Engine Speed: 2400rpm
17. Min. Fuel Consumption Rate: 210g/kW.h
18. Transmission Mode: ZL280 Hydraulic Torque Converter
19. Gear Shift: 1 Forward, 1 Reverse, 1 High Speed, 1 Low Speed
20. Max. Speed: 25km/h
21. Mode of Axle:ZL20 Hub Reduction Drive Axle
22. Wheel Tread: 1650mm
23. Wheel Base: 2600mm
24. Drive Mode: 4-wheel Drive
25. Hydraulic System Working Pressure: 20Mpa
26. Hydraulic System Working Pump Type: Gear Pump
27. Service Brake: Foot Pedal Vacuum Booster, Air over Hydraulic Caliper Disc Brake on 4 Wheels
28. Parking Brake: Hand Lever Flexible Shaft Controlled Disc Brake
29. Tyre Type Specification: 16/70-24-16PR
30. Front Tyre Pressure: 0.40Mpa
31. Rear Tyre Pressure: 0.35Mpa

Note:
1. All photos are for reference only.
2. Machines shown may include optional parts.
3. All specifications and design characteristics are subject to change without prior notice.
